HOWO 8X4 Dump Truck

Powerful and reliable dump truck designed for heavy-duty construction and mining operations.

HOWO 8X4 Dump Truck
HOWO 8X4 Dump Truck
HOWO 8X4 Dump Truck Side View
HOWO 8X4 Dump Truck Interior
HOWO 8X4 Dump Truck Loading

Product Overview

The HOWO 8X4 Dump Truck is a heavy-duty vehicle designed for the most demanding construction and mining applications. With its powerful engine, robust chassis, and high-capacity cargo body, this truck delivers exceptional performance in even the harshest environments.

Built by Sinotruk, one of China's leading commercial vehicle manufacturers, the HOWO 8X4 Dump Truck combines advanced technology with rugged reliability to provide a cost-effective solution for your material transportation needs.

Key Features

  • Powerful Weichai diesel engine with 380-400 HP
  • HW19710 10-speed transmission for optimal performance
  • Large cargo body with 22-30 CBM capacity
  • Robust 8X4 drive system for excellent traction
  • Comfortable cabin with air conditioning and power steering

Engine Power

380-400 HP

Drive Type

8X4

Cargo Volume

22-30 CBM

Technical Specifications

Detailed specifications of the HOWO 8X4 Dump Truck. Click on the tabs to view different categories.

Model ZZ3317V3567B1
Driving Type 8x4 / 12 wheels / 4 axles
Horse Power 380HP / 400HP
Transmission HW19710, 10F & 2R
Cargo Body Volume 22CBM / 26CBM / 30CBM
Overall Dimension 10750*2550*3450mm
Cabin HW76, with one sleeper and two seats
Steering ZF power steering, model ZF8118
Brake System Dual circuit compressed air brake
Electrics 24V, negative grounded
Engine Make Weichai Diesel
Engine Model WP10.380E22, Euro 2
Horse Power 380HP
Configuration 6-cylinder in-line
Cooling System Water cooling
Aspiration Turbo-charging and intercooling
Displacement 9.726 L
Fuel Type Diesel
Fuel Tank Capacity 300L
Emission Standard Euro 2 (Euro 3/4/5 optional)
Transmission Model HW19 710
Gears 10 forward, 2 reverse
Gear Ratios 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
PTO Available
Clutch Dry single plate with hydraulic booster
Propeller Shaft Double universal joint with gear-shaped coupling flange
Frame U-profile parallel ladder frame with section of 300x80x8mm
Front Axle VGD95, 2x9000 KGS
Rear Axle MCX16ZG, 2x16000 KGS
Rear Axle Ratio 5.73
Front Suspension 10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
Rear Suspension 12 leaf semi elliptic springs, bogie spring and stabilizer
Tires 12.00R20, radial tyres with one spare tyre
Wheelbase 4300+1350mm
Cargo Body Dimensions 7300*2300*1700 mm
Cargo Body Volume 28.5 CBM
Floor Thickness 10mm
Side Thickness 8mm
Material High strength steel
Tailgate Type Upper opening
Lifting System Hydraulic
Maximum Dump Angle ≥45°

Performance Data

Compare the performance metrics of the HOWO 8X4 Dump Truck with industry standards.

Fuel Efficiency Comparison

Load Capacity vs. Competitors

Application Scenarios

The HOWO 8X4 Dump Truck is suitable for a wide range of applications across various industries.

Construction Sites

Ideal for transporting construction materials such as sand, gravel, and concrete at building sites.

Mining Operations

Perfect for hauling ores, coal, and other materials in mining and quarrying operations.

Infrastructure Projects

Suitable for large-scale infrastructure projects like road construction and dam building.
